China 0.2-2X1250mm Hydraulic Slitting Line China Manufacturer

China 0.2-2X1250mm Hydraulic Slitting Line

Basic Info

Model NO.: as to your request

Applicable Process: Process Materials

Suitable Substrates: Film Cutting

Packaging Material: Wood

Control Model: Frequency Conversion Control

Material: Crs/Galvanized Steel Coils

Crs/Galvanized Steel Coils: 0. 2-2.0mm

Width(Max): 1250mm

Coil ID: 508mm

Line Speed: <=40m/Min Quantity of Strips Can Slit (Max): 10strips

Power of Decoiler: 7.5kw

Power of Recoiler: 11kw

Cutting Accuracy: 0.02mm

Trademark: WILLING INT′L

Transport Package: Sea Package

Specification: CE, ISO9001, GMC

Origin: China

HS Code: 84623910

Product Description

1. Main Parameters
Material: cold rolled steel coils /colour-coated steel coils /aluminum coils
Thickness: 0.25mm ~ 1.0mm
Width: max. 100-1250mm
Line speed: max. 20m/min
Machine size: 1700*1300*1200mm (length * width *height)
Numbers of slitting: max. 9 slits
Cutting accuracy: 0.02mm
Equipped with simple controller

2. Other terms
1) All the parts above composed the whole slitting line. It is safe and stable in actual use and is very convenient.
2) If you need add the spare parts, please do the extra purchase.
3) We can provide the line recently as it is stocked in our workshop.

FAQ
Q:Are you a manufacturer?
A:Yes absolutely. Welcome a lot for your visiting to us.
Q:What's the delivery time?
A:Normaly will take 60days
Q:Do you have after-sale support?
A:Yes, we're always here for giving you advice and support for technical details since we have senior technician.
Q:Is there quality control when manufacturing the lines?
A:Yes, we have a group of team who will be responsible for quality control from laying off the raw material, processing the rollers and the other parts, make treatment srcid= ' 46601825 ' src= ' /upLoad/et29867302138214.jpg ' width= ' 639px ' height= ' 301px ' />
