China 4X1350mm Full Automatic High Precision Silicon Steel Slitting Line or Cut to Length Line for Sale

Basic Info

Model NO.: Customized

Material: Metal

Power: 22kw

Trademark: HAOSHUO

Transport Package: Sea Shipping by Container

Specification: customized

Origin: Wuxi, China

HS Code: 84552290

Product Description

4x1350mm full automatic high precision silicon steel slitting line or cut to length line for sale

Product description

1.This automatic silicon steel slitting line can cut automatically silicon steel coil to certain length with various shapes. It is necessary production equipment in transformer manufacturing.
2.The silicon steel cut to length line can be suitable for cutting series of silicon pieces, which are used for transformer core lamination. For example, it can do 45 degree and 135 degree shear. It also can shear from transverse and longitudinal angle. This silicon steel cut to length line can make V notches and punch holes.

Model

ZJX1000

ZJX1250

Coil thickness

Silicon steel 0.23-0.35mm

Max width of coil

1000mm

1250mm

Slitting speed

0-80-120m/min

Slit width

Min 20mm

Width precision

?.1mm

Edge linear straightness

?.1mm/m

Strip burr

Less than 0.02mm

Coil weight

5tons

10 tons

Main components
1.Double Head Decoiler
2.Servo Feeder
3.V-shaped Punch
4.Shears 1
5.Shears 2
6.Discharge Units(Belt)
7.Stacking Table
8.Controlling System

Working process

Coil decoiling - Speed adjusting - servo feeding for length measuring - servo positioning pneumatic V notching - pneumatic hole punching - -45 degree pneumatic shearing - 45 degree pneumatic shearing - servo track positioning - work pieces feeding & collecting - automatic product stacking
Our service
One stop service for customized machine
Overseas installation & operating training
One year warranty of the whole machine
Life-long technical support
