China Cut to Length Line (uncoiling machine, leveling machine, cutting machine, stacking machine) China Manufacturer

China Cut to Length Line (uncoiling machine, leveling machine, cutting machine, stacking machine)

Basic Info

• Model NO.: TQ44K-1.8×2000
• Layout: Horizontal
• Automatic Grade: Automatic
• Cutting Mode: Blade
• )Voltage: Customized
• Color: Optional
• Trademark: KINGWELL
• Specification: CE
• HS Code: 84623990

• Customized: Customized
• Cutting Material: Copper, Carbon Steel, Iron, Aluminum, Metal Alloy
• Power Source: Electric
• Support OEM: Yes
• Guarantee Period: 12 Months After Delivery
• Processing Object: Cold/Hot Rolled,Galvanized,Stainless,Carbon Steel
• Transport Package: Steel Pallet
• Origin: Nantong, China

Product Description

QR稵Q44K-1.8?000mm Cut To Length Line
Uncoiling machine /Leveling machine /Cutting machine/Stacking machine
1. Application :
This cut to length line can be used for leveling and cutting coils into required length. Steel boards are pressed again and again between the rollers which are working for leveling to eliminate strain in order to get leveled.
This line is mainly used in manufacturing of smelting, car, metal structure, shipping , compression container and container etc. And used in the field of metal storage, board distribution etc.
The function can be extended if it is used with the relative equipment as required by the customers.

2. Parameters NO.NAMEPARAMETERUNITNOTE1Coil thickness 0.5-1.8mm 2Coil width 800-2000mm 3Inner diameter of the coil480-520mm 4Outer diameter of the col≤1600mm 5Feeding speed0-30m/min 6Coil weight≤15T 7Length tolerance≤?/span>1.0mm/2000mm 8Flatness tolerance(mm/m2)≤?/span>1.5mm/sqm 9Application materials Cold-rolled, Galvanize
3. Main component equipment

1. Loading cart
2. Uncoiling machine
3. Correcting facility
4. Leveling machine
5. Loop bridge
6. Length fixing facility
7. Shearing machine
8. Material conveying facility
9. Stacking machine
10. Unloading cart
11. Hydraulic control system
12. Electric control system




