China Economical Cut to Length Line China Manufacturer

China Economical Cut to Length Line

Basic Info

• Model NO.: CAH(22)-300JY
• Origin: China

• Trademark: CANWIN
• HS Code: 84623120

Product Description

The main technical parameters

1. The processing range:
Thickness: 0.23-0.35 mm
Wide: 40-320 - mm (normal form)
60-300 - mm (step shape)
Length: 400-2000 - mm (length from the center line)
Punching diameter: ? - ?24 mm

2. This production line used by the coil material requirements:
The width tolerance: / - 0.1 mm
MAO thorn: 0.03 mm or less
S: of the deviation in height= ' 470px ' srcid= ' 145436635 ' width= ' 704px ' src= ' /upLoad/et30118302159153.jpg ' />

4. The feeding speed, working feed speed 150 m/min

5. The knives' service life: each grinding is not less than 1 million for the first time, tungsten carbide material
Die life: not less than 20-300000 times (once every grinding) : cemented carbide materials.

6. The total installed capacity: about 16 kw

7. The total gas consumption: 1 m?min

8. The working conditions:
(1) the temperature is not higher than 40 ?C;
(2) voltage fluctuation to 380 v 10%;
(3) the frequency of 50 hz

9. With vertical and horizontal three, five, seven step function
10. Operating direction: right line (from>




GUANGDONG CANWIN AUTOMATIC EQUIPMENT CO., LTD.

Guangdong, China

Manufacturer/Factory, Trading Company

Gold Member Since 2017

Audited Supplier

• OEM/ODM Service
• Factory Tour

Main Products: Cut to Length Line, Slitting Line
