China EVA Sheet Making Machine & EVA Vulcanizing Press

Basic Info

Model NO.: XLB-100*1000*6

Power: 10~100kw

Voltage: 380V/415V/450V/220V

Using Life: More Than 15 Years

Delivery Time: 30 Days

Warranty: 2 Years

Advantage: Low Noise and High Safety

Heating Mode: Electrical/Oil Heating

Trademark: Yefei

Transport Package: Exporting Standard(Wooden Box Packing)

Specification: all various

Origin: Qingdao, China

HS Code: 8477800000

Product Description

Advantages:

1. Low energy consumption
2. Convenient in maintenance
3. Simple operation

We have ISO9001: 2008, SGS, CE standard and offer all kinds of certification according to customer's request: Like CO, CIQ, SASO and so srcid= ' 65805812 ' src= ' /upLoad/et30954302311014.jpg ' width= ' 720px ' />

1. Application

It is mainly in use of vulcanizing various kinds of rubber pattern products.

1) The body use frame type, mainly consist of top crossing, plate, table, piston, hydraulic cylinder and frame. We put asbestos board between plate and top crossing, table, for its good heat insulation. Use polyurethane material sealing ring between piston and hydraulic cylinder with good sealing property. The piston material is chilled cast iron, hydraulic cylinder material is ductile cast iron, weldment between top and bottom crossing.

2) Put holder and oil cylinder at the side of plate, push-off and reseting moulds are finished by oil cylinder moving when using. There is not ejecting holder in manual ejecting mould structure, but still convenient when using.

3) Hydraulic system is consist of unipump, operating valve and control system.

4) Electric system is consist of oil pump motor and vulcanizing timing. When working pressure reach 22.1 mpa, electro connecting pressure gauge control, time relay srcid= ' 65805832 ' src= ' /upLoad/et30954302311016.jpg ' width= ' 720px ' />
