China Fully Automatic Step-Lap CRGO Core Cut to Length Line China Manufacturer

China Fully Automatic Step-Lap CRGO Core Cut to Length Line

Basic Info

Model NO.: Customized

Material: Metal

Power: 22kw

Trademark: HAOSHUO

Transport Package: Sea Shipping by Container

Specification: customized

Origin: Wuxi, China

HS Code: 84552290

Product Description

Fully automatic step-lap CRGO core cut to length line

Product description
The automatic step-lap CRGO core cut to length line can cut stepped core pieces, different shapes of the silicon pieces with V notching and hole punching. The machine has high automation, high speed and high production performance
The line speed is very fast, after cutting, the pieces shall be collected and stacking automatically. Different shapes of pieces will be placed independently.

Item

HJX300

HJX400

HJX600

Coil weight

1000kg

CRGO coil width

30-330mm

40-440mm

60-660mm

Thickness

0.23-0.35mm

Length accuracy

?.2mm

Cutting burr

≤0.02mm

HMI

10.4 ' touch screen

Total power consumption

20KW

30KW

35KW

Line dimension

17.5m x 4.0m x 2.5m

17.5m x 4.2m x 2.5m

17.5m x 4.5m x 2.5m

Total gross weigth

16 tons

17 tons

19 tons

Main components

Double Head Hydraulic Powered Decoiler

Speed Control Plate with Sensor in Buffer Pit

Servo Feeding Device

Pneumatic V Notch Machine with Servo Positioning

Pneumatic Hole Punching Machine

Pneumatic 135?or called -45? Shearer(can be adjusted to 0?

Pneumatic 45?Shearer

Servo Rail Positioning Device

Belt Conveyer with Safety Guard

Collecting Conveyer with Auto Stacking

Product Stacking Trolley

Operation & Controlling Cabinet

Working process

Coil decoiling - Speed adjusting - servo feeding for length measuring - servo positioning pneumatic V notching - pneumatic hole punching - -45 degree pneumatic shearing - 45 degree pneumatic shearing - servo track positioning - work pieces feeding & collecting - automatic product stacking

Our service
One stop service for customized machine
Overseas installation & operating training
One year warranty of the whole machine
Life-long technical support
