China High Speed Thermal Paper Slitting Line (JT-SLT-900) China Manufacturer

China High Speed Thermal Paper Slitting Line (JT-SLT-900)

Basic Info

Model NO.: JT-SLT-900

PLC: Emerson

Touch Screen: High Tech From Taiwan

Rewinding Type: Inverter Motor Drives Magnetic Clutch

Auto Tension: 2 Sets, Inplant The PLC

Synchronic Belt: From Germany

Speed: 150m/Min

Machine Type: Slitter Rewinder

Unwinding Type: Magnetic Brake for Unwinding Tension

Cutting Type: Disc Blades

Red Line Marker: Yes

Trademark: Jota Machinery

Specification: ISO9001, CE

Origin: Ruian, Zhejiang, China

HS Code: 84411000

Product Description

High Speed Thermal Paper Slitting Line
Two Ply Thermal Cash Register Printing And Slitting Machine
--Slitting Machine
--Emerson PLC
--Touch Screen Control
--Auto Tension Control System
--Meter Counter
--This Slitting Machine is used for slitting fax paper, cash register paper, film, self-adhesive trade marks, and other paper less than 250GSM. It is advanced equipment at home and abroad.

--This Slitting Machine adopts sureface rewinding system to slit the small roll fax paper or cash register paper.

--We can provide the rewinding shaft in diameter of 12.7mm, 25.4mm and 50.8mm. Some other size is subject to the clients demand.

Max. Unwinding Width: 900-1200mm
Max. Unwinding Diameter: 1000mm
Max. Rewinding Diameter: 200mm
Max. Slitting Speed: 120m/min
Frequency inverter motor: 2.2Kw
Overall Dimension: 2050*1600*1500mm
Weight: 1500kg.

Model TypeJT-SLT-900Max. Parent Web Width900mmMax. Parent Web Diameter1000mmMax. Rewinding Diameter160mmMin. SlittingWidth28mmMax. Speed150m/minUnwinding Shaft3 ' Air Expanding ShaftRewinding Shaft0.5 ' , 1 ' , 1.5 ' 2 ' are available(or as request)Voltagethree-phase four-wire, 380V,50HZPower2.2kwWeight1600kgOverall Dimensions(LxWxH)2000x1700x1500mm
