China Slitting Line for Cut to Length Line

Basic Info.

Model NO.:Cut to Length Machine
Type:Balance Roller Straightening Machine
Usage:Sheet
Voltage:220V
Automatic Grade:Automatic
Principle:Large Deformation
Certification:CE
Warranty:24 Months
Customized:Non-Customized
Condition:New
Suitable Material:Colored Armor Plate
Thickness of The Plate:0.3- 1.5mm
Input Width of The Plate:1500 mm
Control System:PLC Control System
Productivity:15-25 M/Min
Roller Material:45# Steel or Rubber Shafts
Max Thickness of The Raw Material:3 mm
Transmission Chain Is 25:25.4mm
(13) Material of The Cutting Blade:Cr12
Trademark:Huantu machinery
Specification:1000-2000mm
Origin:China
HS Code:8462312000

Product Description

Slitting Line for Cut to Length Line

Parameters of Rotary Shear
Model/ Items
Thickness (mm)
Width (mm)
Shearing Accuracy (mm)
Max. Line Speed m/min
Max. Cutting Speed (spm)
Coil Weight (ton)
2x650

0.2-2
100-650
?.3/1000mm
60
150
8
2x800

0.2-2
100-800
60
150
82x1300
0.3-2
400-1300
70
150
152x1600
0.3-2
400-1600
70
150
15
3x1600

0.4-3
400-1600
70
120
15 Components of lineNo.NameUnitQty1Feeding tableset12Main machine for levelingset13Control systemset14Hydraulic systemset15Post cutset1

Features of Cut to Length Line
1. Our cut to length line uses a roll feeding, AC servo drive.
2. It has a fully digital length control system that ensures fast positioning with little error.
3. It has a hard chrome plated surface and is durable and abrasion resistant.
4. It is used together with a hydraulic shear or an air-clutch shear to carry out fast shearing and convenient clearance adjustment.
5. Our cut to length line is suitable for hot rolling carbon steel, tinplate, stainless steel, and other kinds of metals with coated surfaces.
6. High degree of automation, easy & reliable operation
7. High length precision, high sheet flatness
8. Good order stacking

Work Process

Coil decoiling -- buffer plate for coil storage -- servo feeding for length measuring -- electric hole punching -- servo positioning -- servo V notching -- cutting coil sheet into required shapes by 2 shearers -- work pieces feeding & collecting -- automatic product stacking

Slitting Line
